Atlantic 24" Complete Basin Kit – Disappearing Fountain Reservoir for Bubbling Rock, Urn & Patio Water Features

The CFBASINKIT24 is an all-in-one formal spillway basin system. It includes:

• CFBASIN24 basin — 44"W × 22"D × 16"H, 33-gallon one-piece reservoir with integrated filtered pump chamber, built-in plumbing channels, and Lifetime Warranty
• TT3000 TidalWave3 Asynchronous Pump — 3,000 GPH, 173W, 20' cord, 3-year limited warranty
• Matala splash mat — pre-filters debris and reduces splash loss
• AF1000 AutoFill valve — automatically maintains water level; no manual top-off needed
• Flexible PVC pipe (verify diameter with Atlantic before ordering supplemental fittings)
• Single union flow/adjustment valve
• PVC spray glue + thread sealant
• All necessary fittings and hardware
• Instruction manual

The spillway (Colorfalls, Scupper, WaterWall, or WaterSpout) is not included and must be purchased separately.

The CFBASINKIT24 is engineered for use with all Atlantic 24" formal spillways, including:

• Classic Colorfalls and Color Changing Colorfalls (24" wide)
• Stainless Steel Scuppers (24" wide)
• Copper Scuppers (24" wide)
• WaterWalls (24" wide sheet waterfall spillways)
• WaterSpouts / Wall Spouts (24" compatible)

The CFBASIN24 reservoir's 44" wide footprint is designed to capture splash from all 24" spillways without water loss. The basket handles the basin’s 33-gallon water volume and integrates with the TT3000’s 3,000 GPH output to maintain ideal flow for any 24" spillway head.

The Matala splash mat serves two important functions in the CFBASINKIT24 system:

• Splash control: It covers the basin opening, containing water returning from the spillway and preventing it from splashing outside the reservoir footprint. This reduces water loss from evaporation and splash and keeps surrounding hardscape dry.
• Pre-filtration: The open-cell Matala material traps leaves, debris, and particulates before they can enter the pump chamber, keeping the TT3000 TidalWave3 pump running efficiently between cleanings.

The splash mat can be covered with decorative stone or gravel (matching the spillway wall installation) for a clean, professional finish that conceals the basin while still allowing water to return freely.

Yes — Atlantic specifically designed the CFBASIN24 for seamless installation with standard 4" garden block. Its rectangular footprint and rigid walls allow retaining wall block to be built directly against the basin exterior for a fully integrated, built-in formal water feature appearance.

The basin can be installed:

• In-ground (below grade): Excavate a trench of at least 44"W × 22"D × 16"H. Set basin level in compacted soil. Build retaining wall up from ground level on all sides to conceal the basin and support the spillway above.
• Above ground (raised feature): Build a block retaining wall to the desired height; set the basin into the wall cavity. Useful for raised patio planters or freestanding formal water walls.

The built-in plumbing channels within the basin wall route tubing between the pump chamber and the spillway connection point without cutting or drilling.

No. Every CFBASINKIT24 includes the AF1000 AutoFill valve, which automatically monitors and maintains the water level in the CFBASIN24 reservoir. When water drops below the set level — due to evaporation or splash — the AutoFill opens and introduces fresh water from a connected garden hose supply until the correct level is restored, then closes automatically.

The TT3000 pump requires a minimum water level to operate correctly; the AF1000 ensures the pump is always submerged without any manual monitoring. For installation, the AF1000 connects to a standard garden hose fitting at the basin wall.

The CFBASINKIT24 carries two separate warranties:

• CFBASIN24 basin: Lifetime Warranty — Atlantic stands behind the one-piece basin construction for the life of the product under normal installation and use conditions.
• TT3000 TidalWave3 pump: 3-Year Limited Warranty — covers the pump against defects in materials and workmanship for 3 years from the date of purchase.

For warranty service, contact Pond Pro Direct at (765) 508-4352 or support@pondprodirect.com. We carry authentic Atlantic Water Gardens products with full manufacturer warranty support.

The included TT3000 TidalWave3 Asynchronous Pump is Atlantic's high-efficiency, compact-design waterfall and feature pump. Full specifications:

• Max flow rate: 3,000 GPH
• Motor: 173W asynchronous (more flow per watt than traditional designs)
• Voltage: 115V | Amperage: 1.5A
• Max head height: 19.5 feet
• Power cord: 20 feet
• Inlet: 1½" MIPT | Outlet: 1½" MIPT/FIPT (step fitting 1"–1½" included)
• Dimensions: 8"L × 5¼"W × 6¼"H
• Pre-filter: Ribbed design with large openings; clog-resistant; hard water tolerant
• Can be operated vertically or horizontally
• 3-Year Limited Warranty

The TidalWave3's asynchronous motor combines the efficiency of magnetic induction with the power of direct-drive geometry — delivering up to 35% energy savings versus previous TidalWave generations at equivalent flow rates.

The CFBASINKIT24 system is designed for minimal ongoing maintenance:

• Matala splash mat: Lift and rinse periodically to remove accumulated debris. Frequency depends on surrounding landscaping (fall leaves require more frequent cleaning). The Matala material is washable and reusable.
• TT3000 pump: The ribbed pre-filter cage is designed for clog resistance. For cleaning, remove the pump from the chamber and rinse the pre-filter screen. The pump can be disassembled without tools for impeller access if needed.
• AutoFill valve: Check the AF1000 inlet screen periodically for mineral buildup in hard water environments. Clean with a mild vinegar solution if flow is restricted.
• Basin: Flush the 33-gallon reservoir annually to remove silt. The basin drain can be used for complete drainage during deep cleaning or winterization.

Both are part of Atlantic's formal spillway basin family, but sized for different spillway widths and installation scales:

• CFBASINKIT24 (this kit): For all 24" spillways. Basin: 44"W × 22"D × 16"H, 33-gallon. Pump: TT3000 (3,000 GPH, 173W). Best for single-column or medium formal water features with 24" Colorfalls or Scuppers.
• CFBASINKIT36 (SKU 00582): For all 36" spillways. Basin: 56"W × 24"D × 16"H, 42-gallon. Pump: TT4000 (4,490 GPH, 230W). Larger basin and more powerful pump for wider spillways, WaterWalls, and more dramatic formal features.

Both kits include the AF1000 AutoFill, Matala splash mat, PVC glue, thread sealant, and adjustment valve. The key differences are the basin footprint, reservoir volume, and pump capacity. Choose based on your spillway width.

The CFBASIN24 is versatile — it can be installed above or below ground. Atlantic's own product description confirms both options are supported by the basin's one-piece construction and rigid walls.

Below ground (most common): Dig a trench at least 44"W × 22"D × 16"H. Set the basin on a level, compacted base. Build retaining wall block around it and position the spillway on the wall above. The basin lid sits flush with grade and is covered by the Matala mat and decorative stone.

Above ground: Build a block surround to the desired height and set the basin in the cavity. Useful for raised patio planters, elevated formal features, or installations where excavation is not possible. Ensure the block structure fully supports the basin and the weight of the water when filled.

In both configurations, the AF1000 AutoFill connects to a nearby water supply and the TT3000 pump connects to the spillway via the included PVC pipe and adjustment valve.
