EasyPro EL2424 Pro-Series 24' x 24' Large Pond Kit – Complete Koi Ecosystem System
✓ 30-Day Return Period
✓ Price Match - We will Beat Lower Prices!
✓ Secure Encrypted Checkout
✓ Questions? - Call (765) 508-4352
Description
The EasyPro EL2424 Pro-Series™ Large Complete Pond Kit is a professional-grade, all-in-one system for building a 24' × 24' ecosystem pond holding approximately 10,000 gallons. Every component is factory-matched and sized together — the PS2FB skimmer, AquaFalls™ AL filter, TM9500 pump, and 30'×30' DuraLiner™ EPDM liner are all specified as a system for this pond footprint, eliminating the guesswork and compatibility risk of sourcing components individually.
EasyPro's Pro-Series is the contractor-preferred choice for koi pond and ecosystem pond builds. The Axiom-derived PS2FB skimmer and AquaFalls™ AL filter are designed for high bioloads — the 15,000-gallon-capable filter and 18,000-GPH-rated skimmer give this 10,000-gallon pond substantial margin for heavy koi stocking or demanding water quality requirements.
Due to the unique nature of large pond installations, EasyPro recommends custom design consultation before breaking ground. Our team at Pond Pro Direct specs large EasyPro Pro-Series builds daily — call or text (765) 508-4352 and share your site dimensions, desired depth, and fish stocking plan. We can recommend the right configuration and confirm component compatibility before your order ships.
Complete Component List — EasyPro EL2424
- 30' × 30' DuraLiner™ 45-mil EPDM (Firestone-manufactured)
- Liner underlayment
- Liner patch (in WIK2 kit)
- Large Pro-Series™ Skimmer (PS2FB)
- 42" × 20" × 30" body
- 16" weir opening
- 18,000 GPH max flow capacity
- Filter brushes included
- Large Pro-Series™ AquaFalls™ filter/waterfall base (AL Series)
- 36" × 65" × 36" body
- 50" spillway width
- 15,000 gallon max pond capacity
- Two 3" inlets
- EasyPro TM9500 (TM Series) submersible pump
- 9,500 GPH max flow
- 31' max head height
- 10.9 amps / 1 HP
- 30' power cord
- 2-year limited warranty
- 3" × 50' flexible PVC pipe
- 3" check valve assembly
- All necessary fittings
- 4 underwater lights with transformer
- 1 gallon All Season Liquid Bacteria (ASB128)
- WIK2 installation kit (PVC primer, PVC glue, liner patch, black foam, two tubes silicone)
Component Technical Specifications
Skimmer — Large Pro-Series™ PS2FB
| Spec | Value |
|---|---|
| Model | PS2FB (Large Pro-Series™) |
| Dimensions | 42" L × 20" W × 30" H |
| Weir Opening | 16" |
| Max Flow Rate | 18,000 GPH |
| Filter Media | Filter brushes |
Waterfall Filter — Large Pro-Series™ AquaFalls™ AL Series
| Spec | Value |
|---|---|
| Model | AL Series (Large Pro-Series™ AquaFalls™) |
| Dimensions | 36" L × 65" W × 36" H |
| Spillway Width | 50" |
| Max Pond Size | 15,000 gallons |
| Max Flow Rate | 15,000 GPH |
| Inlet Connections | Two 3" inlets |
Pump — EasyPro TM9500
| Spec | Value |
|---|---|
| Model | TM9500 (TM Series) |
| Max Flow Rate | 9,500 GPH |
| Max Head Height | 31 feet |
| Power | 1 HP / 10.9 amps |
| Discharge | 3" |
| Power Cord | 30 feet |
| Warranty | 2-year limited |
Kit Technical Specifications
| Specification | Value |
|---|---|
| Kit Model | EL2424 |
| Pond Footprint | 24' × 24' |
| Pond Volume (3' depth) | ~10,000 gallons |
| Liner | 30' × 30' DuraLiner™ 45-mil EPDM (Firestone-manufactured) |
| Skimmer | Large Pro-Series™ PS2FB — 16" weir, 18,000 GPH capacity |
| Waterfall Filter | Large Pro-Series™ AquaFalls™ AL Series — 50" spillway, 15,000 gal max |
| Pump | EasyPro TM9500 — 9,500 GPH / 31' max head / 10.9A / 30' cord / 2-yr warranty |
| Tubing | 3" × 50' flexible PVC |
| Check Valve | 3" check valve assembly |
| Lighting | 4 underwater lights with transformer |
| Bacteria | 1 gallon All Season Liquid Bacteria (ASB128) |
| Install Kit | WIK2 — PVC primer, glue, liner patch, black foam, 2× silicone tubes |
| Recommended Depth | 3 feet (2.5–4' acceptable; 3' standard design assumption) |
Frequently Asked Questions
What specific components are included in the EasyPro EL2424 24'×24' Kit?
The EL2424 includes:
- Liner: 30' × 30' DuraLiner™ 45-mil EPDM (Firestone-manufactured) + liner underlayment
- Skimmer: Large Pro-Series™ PS2FB (42"×20"×30", 16" weir, 18,000 GPH)
- Filter/Waterfall: Large Pro-Series™ AquaFalls™ AL Series (36"×65"×36", 50" spillway, 15,000 gal max, two 3" inlets)
- Pump: EasyPro TM9500 (9,500 GPH, 31' head, 10.9A, 30' cord, 2-year warranty)
- Plumbing: 3"×50' flexible PVC pipe + 3" check valve assembly + all necessary fittings
- Lighting: 4 underwater lights with transformer
- Bacteria: 1 gallon All Season Liquid Bacteria (ASB128)
- Install kit (WIK2): PVC primer, PVC glue, liner patch, black foam, two tubes silicone
Not included: Rocks, boulders, gravel, aquatic plants, fish.
How many gallons does the 24'×24' EasyPro pond hold?
At the standard recommended depth of 3 feet average (with typical perimeter shelving), the EL2424 pond system holds approximately 10,000 gallons. This volume provides excellent thermal stability for large koi and supports a diverse ecosystem population.
The AquaFalls™ AL filter is rated for ponds up to 15,000 gallons, and the PS2FB skimmer handles up to 18,000 GPH — both providing significant margin above the 10,000-gallon pond volume for demanding koi stocking scenarios.
What is the AquaFalls™ filter and how does it work?
The EasyPro AquaFalls™ AL Series is a large biological waterfall filter — the biological filtration heart of the EL2424 ecosystem. It provides a massive surface area for nitrifying bacteria via filter brushes and optional Matala media, which process fish waste (ammonia → nitrite → nitrate) before water returns to the pond.
Key specs: 36"×65"×36" body, 50" spillway width (producing a wide, dramatic waterfall), rated for ponds up to 15,000 gallons, and accommodates up to 15,000 GPH flow. Its molded rock-lip design creates a natural waterfall spillway appearance with no leakage. The wide spillway produces a full-width waterfall sheet across the entire 50" opening at design flow rates.
Note for PPD shoppers: The AquaFalls™ is EasyPro's own biological filter system — distinct from and unrelated to BioFalls® (Aquascape's competing product). Both serve the same function but are different products from different manufacturers.
Can I keep a large population of koi in the EL2424 system?
Yes — the Pro-Series filtration is specifically designed for high bioloads. The PS2FB skimmer (mechanical filtration, removes surface debris before it reaches the pump) combined with the AquaFalls™ AL filter (biological filtration, processes dissolved fish waste) form a matched two-stage system sized well above the pond volume.
- Standard koi stocking: 1 inch of fish per 10 gallons — a 10,000-gallon pond can support up to 1,000 inches of fish (roughly 25–30 adult koi at 12–18 inches) at standard stocking
- Heavy koi stocking: For maximum fish density (show-pond stocking), consider supplemental aeration and periodic water testing to ensure ammonia and nitrite remain at zero
- Depth recommendation: For koi health, 3–4 feet minimum depth in at least one zone provides thermal refuge in summer and winter survival in northern climates
How energy-efficient is the TM9500 pump included in this kit?
The EasyPro TM9500 is a 1 HP (10.9-amp) submersible waterfall pump delivering 9,500 GPH at 0-foot head, with a maximum head height of 31 feet. At a typical 24'×24' installation head of 3–5 feet, the pump delivers its rated near-maximum flow to the AquaFalls™ filter.
EasyPro's TM Series pumps are designed for continuous 24/7 operation in skimmer housing, with oil-free construction and stainless steel components for long-term submerged reliability. The 2-year warranty covers the pump for normal pond operation. At 10.9 amps on a standard 120V circuit, the pump draws approximately 1,308 watts — comparable to a small electric heater. Running 24/7, monthly operating cost at $0.12/kWh is approximately $113/month. Many pond owners run waterfalls 12–16 hours/day in off-peak months to reduce costs.
What is the maintenance schedule for the PS2FB Skimmer?
The PS2FB skimmer uses filter brushes rather than foam pads, which reduces maintenance frequency and makes cleaning faster. General schedule:
- Weekly (peak season): Check and empty the debris basket (leaves, skimmed surface material)
- Every 1–2 weeks: Rinse filter brushes — agitate in a bucket of pond water (never tap water, which kills beneficial bacteria)
- Monthly: Inspect pump intake screen; remove any algae or biofilm buildup on intake housing
- Fall: More frequent basket emptying during leaf season — daily during heavy leaf fall is not unusual for a 24'×24' pond surrounded by trees
The PS2FB's 16" weir efficiently pulls surface debris before it sinks, protecting pump longevity and significantly reducing bottom vacuum frequency.
Why Buy from Pond Pro Direct?
- Authorized EasyPro dealer — full manufacturer warranty including 2-year TM9500 pump warranty
- Large pond spec expertise — we spec Pro-Series and Eco-Series builds daily; call (765) 508-4352 for custom design guidance on your site
- Price Match Guarantee — beat any lower authorized dealer price by $50 on orders over $2,000
- Free shipping
- 30-day return period
